SDO5 SMART Plus garage door operator, boasts whisper-quiet operation thanks to its state-of-the-art mechanical design, extended battery life for uninterrupted convenience during power outages and SMART technology for quick and easy setup.
Mains driven and battery backup ready
The SDO5 SMΔRT+ plug and play for battery backup if necessary.
Sleek new aesthetic low-profile design
A modern motor that complements your garage, no bulky battery box.
More visibility and control
Always-on cloud connectivity lets you check your gate status, and control your gate remotely from the MyCentsys Remote app.
Wireless wall pendant
Comes with a Wireless Wall Pendant for convenient control, adding another layer of ease and accessibility (not included with T10).
Stay informed, stay protected
A built-in tamper sensor indicates tampering with the door or operator, and the door service monitor helps you stay on top of maintenance timing.
The SDO5 SMΔRT+ T12 is ideal for;
- Larger and heavier garage doors
- Residential installations requiring high-power automation
- Projects demanding extra control and functionality thanks to an included Wireless Wall Pendant
- Sectional garage door configurations
Kit Includes
- 2 x 4-Button NOVA Remotes
- Wall Pendant
- Sectional Track Belt
- 2 x 2.9Ah Battery Backup kit
Main Features
- AC Driven
- Model options: T12
- Drive system: Belt drive for quiet garage operation
- Safety: Built-in collision sensing with auto-reverse; adjustable sensitivity
- 24V drive system: mains powered, with T12 delivering extra drive power for larger setups
- Connectivity: BLE and Wi-Fi, Stay continuously connected to your garage door motor with real-time status updates and smart monitoring at all times.
- Accessories integration: Two configurable input/output channels and one input
- Receiver capacity: 30 x 4-Button Transmitters
Specifications
- Input voltage 220V - 240V AC @ 50/60Hz
- Motor voltage 24V DC
- Motor power - rated 100W DC
- Motor supply
- Mains driven
- 150 VA Thermally fused
- Toroidal Transformer
- Max door width 6500mm
- Max holding capacity 1200N
- Maximum push/pull force 50kgf
- Battery Backup Optional 2.9Ah Battery Backup2 870mA Charging Rate with built-in Battery Saving and testing functionality
- Wireless Communication BLE and Wi-Fi (2.4Ghz)
- Door travel adjustment Physical Endstops (Automatic limit set)
- Receiver code storage capacity 30x 4-button NOVA transmitters
- Infrared safety beams Compatible with Wired or Wireless. (Optional but recommended) Configured in MyCentsys Pro
